Towing AGV vehicle

Introduction of Towing transport AGV vehicle

Towing AGV, also known as Tow Vehicle and Lurking Towing Agv, which can simultaneously pull more than material vehicles to achieve efficient handling.  The latent traction Towing AGV can be equipped with a lifting drum attachment for lifting and docking with the automatic assembly line.Moreover, the Tow Vehicles AGV body can be placed with pallet, material rack, material box, etc for conveying.

Technical specifications of Towing  AGV:
The speed is 10m/min~~60m/min; one-way;

towing agv

Towing transport AGV parameters:

Body models Towing AGV Type
physical dimension L800 * W500 * H500 (mm)
control method PLC / AGV motion control chip (optional)
Navigation mode Magnetic Strip Guidance / Photoelectric Guidance / Laser Guidance (optional)
Walking direction Forward and backward, left and right turn, bifurcation
Communication function Wireless LAN (optional)
Drive mode Differential drive
Drive power supply DC24V, DC48V
Drive the lift mode Manual lift / electric lift
Load capacity 100,300,500,1000 KG (can be customized)
Travel speed 30-45m / min Speed ​​(or custom)
Turning radius The minimum can be up to 500mm (route laying radius)
Navigation accuracy ± 10 mm
Way of working 24 hours
Gradeability 3-5 degrees
Stop Accuracy ± 10 mm
Charging type Manual charging (optional automatic charging)
Battery Maintenance-free rechargeable batteries, the number of continuous discharge> 300 times
Safety sensing range ≤ 3m, adjustable, emergency braking distance of less than 20mm
Human - computer interaction Adopt touch screen man-machine interaction, easy to set parameters, the site and submitted to the warning.
Working Environment Indoor Temperature: 0-40 Celsius Degree Relative Humidity: 40%-80%
Security Protection Front Obstacle Testing Sensor + Mechanical Anti-collision Mechanism + Emergency Button
Design life > 10 years

Towing transport agv Applications:

It is lurking in the bottom of the trolley and the material truck, and realizes automatic logistics delivery and recycling operations without changing the material of the main engine factory.

The Towing AGV uses a tail puller to pull the material trolley, which can simultaneously drive multiple material trucks for efficient handling. The conventional traction AGV requires manual hooking and unloading. The thicker adopts a unique design mechanism to realize automatic unloading, which reduces the labor intensity of the operator and improves the transportation efficiency. The Towing AGV has different models such as 500Kg/1T/2T.
