Natural guidance AGV application in the home appliance industry
DANBACH ROBOT

---

According to the actual needs of customers, AGV adopts natural guidance, two-wheel differential drive, rated load 50kg. The AGV mainly consists of a vehicle body, a transfer mechanism, an electronic control part, a travel drive unit, a safety protection unit, a communication unit, a display and an operation unit.

The workflow of the AGV robot:

1. The tote box is sent from the first floor to the AGV working floor through the elevator, and is transported to the inbound and outbound platform that can be docked with the AGV through the conveyor. The AGV travels to the outbound station to receive the full tote according to the command of the upper system.

2. The AGV sends the tote to the required production line side station according to the system requirements. When the AGV and the station station perform the handshake confirmation by the photoelectric signal, the AGV automatically transports the tote to the unloading station to complete the feeding process.

3. If the empty container recycling station on the production line needs to be shipped back, the AGV will return with an empty box and return it to the empty container returning to the dedicated platform. After a delivery is completed, the AGV automatically detects the power. If it needs to be charged, the AGV automatically charges to the charging position. If no charging is required, the AGV continues to accept the next task.

The production of the home appliance industry and the assembly process of the whole machine require a lot of manpower, and the material distribution on the line occupies a large proportion. The use of AGV can completely replace the original manual distribution, effectively save human resources, reduce the labor intensity of workers, improve the efficiency of logistics and product quality in the factory, and reduce the operating costs of enterprises.
